380V CNC 18 Axis Synchronized Automatic Sheet Metal Bending Machines Folder

380V CNC 18 Axis Synchronized Automatic Sheet Metal Bending Machines Folder
380V CNC 18 Axis Synchronized Automatic Sheet Metal Bending Machines Folder
380V CNC 18 Axis Synchronized Automatic Sheet Metal Bending Machines Folder 380V CNC 18 Axis Synchronized Automatic Sheet Metal Bending Machines Folder 380V CNC 18 Axis Synchronized Automatic Sheet Metal Bending Machines Folder 380V CNC 18 Axis Synchronized Automatic Sheet Metal Bending Machines Folder 380V CNC 18 Axis Synchronized Automatic Sheet Metal Bending Machines Folder 380V CNC 18 Axis Synchronized Automatic Sheet Metal Bending Machines Folder 380V CNC 18 Axis Synchronized Automatic Sheet Metal Bending Machines Folder 380V CNC 18 Axis Synchronized Automatic Sheet Metal Bending Machines Folder 380V CNC 18 Axis Synchronized Automatic Sheet Metal Bending Machines Folder 380V CNC 18 Axis Synchronized Automatic Sheet Metal Bending Machines Folder
Basic Information
Place of Origin: China
Brand Name: MAZS
Certification: CE, ISO
Model Number: MAY-**18
Minimum Order Quantity: 1 Set
Price: RMB/USD/EURO
Packaging Details: wooden case, polystyrene foam and other protective materials suitable for sea transportation
Delivery Time: 60 days to 120 days
Payment Terms: T/T or L/C
Supply Ability: 50 to 60 sets per month
Get Best Price Contact Now
Total Machine Weight: About 19 Tons Material: Metal Plate, Sheet Metal
Name: CNC Sheet Metal Folder Fast Bending Speed: 0.2 Second/time
Packaging: Seaworthy Packing Axis Quantity: Standard Synchronized 18 Axis
Shipping Method: By Sea, Or As Your Required Average Power: About 5.8KW
Highlight:

380V metal bending machines MAZS

,

CNC metal bending machines MAZS

,

18 Axis sheet metal folders MAZS

380V CNC Controlled 18 Axis Synchronized Automatic Sheet Metal Bending

Product Description:

The MAY-18 Axis series is an intelligent flexible bending center that adopts the pressing arm feeding method, which is equipped with three axis and three motors. The machine is designed and produced according to the requirements of high-precision machine tools. It is capable of processing mesh, corrugated, hollow and various flat or special shaped work pieces. Additionally, the deflection compensation can be adjusted via CNC control, effectively extending the bending panel thickness and increasing the comprehensive bending speed. And lastly, it is also applied with fast release and fast installation type upper press tooling.


Features:

We are offering a pressing arm as a feeding method and Y axis double lift automatic positioning tools as a positioning method. The standard axis quantity is 18. It is suitable for stainless steel, aluminum panel, cold panel and other metal materials. There is a metal sheet thickness range from 0.35-3mm. The panel size can reach a maximum of 3200*1500mm. It is suitable for mesh, corrugated, hollow and all kinds of flat panel or special shaped of work piece. Moreover, this method has a lot of funcitons, such as automatic reposition, oblique reposition, improved C axis rotation speed and accuracy, standard power hinge knife, special tooling structure and pneumatic upper pressing tooling, which can bending more thicker panel.


Technical Parameters:

Parameters Values
Total Motor Power 244KW
Packaging Seaworthy Packaging
Material Thickness 0.35-3.0mm
Machine Size 6290*3000*3450mm
Payment Term T/T, L/C
Double Sides Forming Minimum Inner Size 140mm
Name CNC Sheet Metal Folder
Rated Voltage 380V
Max. Bending Size 2500*1500mm
Material Metal Plate, Sheet Metal
380V CNC 18 Axis Synchronized Automatic Sheet Metal Bending Machines Folder 0

Applications:

This automatic intelligent bending center is a perfect tool for steel cabinet shell, such as file cabinets, tool cabinets, electrical cabinet, communication cabinet, gas cabinet, and water meter cabinet. Moreover, it can also be used in kitchenware including refrigerator, air conditioner and stove. What's more, it is an ideal solution for applied fields such as furniture and metal ventilation, purification, door industries, interior decoration, elevator and more.
It successfully assess metal forming problems and offers effective solutions for customers, helping them solve the trouble in the work. Futhermore, it is so smart that it makes it easier for workers to understand the whole bending process as well as the production progresses.
380V CNC 18 Axis Synchronized Automatic Sheet Metal Bending Machines Folder 1

Support and Services:

- Our technical support and service for CNC Sheet Metal Folder covers the following areas:

- Troubleshooting and answering customer inquiries
- Providing technical advice and guidance
- Performing preventive maintenance and repairs
- Carrying out periodic inspections
- Ordering spare parts as needed
- Providing software updates


Packing and Shipping:

Packaging and Shipping of CNC Sheet Metal Folder:
- The CNC Sheet Metal Folder is securely packed in a cardboard box, with foam padding to protect it during shipping.
- The box is then sealed with adhesive tape.
- The box is labeled with the product name and other relevant information for easy identification.
- The product is shipped via a reliable cargo carrier.


FAQ:

Q1:What is the brand name of the CNC Sheet Metal Folder?

A1: The brand name of the CNC Sheet Metal Folder is MAZS.

Q2: What is the model number of the CNC Sheet Metal Folder?

A2: The model number of the CNC Sheet Metal Folder is MAY-**18.

Q3: Where is the CNC Sheet Metal Folder produced?

A3: The CNC Sheet Metal Folder is produced in China.

Q4: What certifications does the CNC Sheet Metal Folder have?

A4: The CNC Sheet Metal Folder has IE and ISO certifications.

Q5: What is the minimum order quantity for the CNC Sheet Metal Folder?

A5: The minimum order quantity for the CNC Sheet Metal Folder is 1 set.
