WUXI MAZS MACHINERY SCIENCE & TECHNOLOGY CO., LTD.
| Place of Origin: | China |
|---|---|
| Brand Name: | MAZS |
| Certification: | CE, ISO |
| Model Number: | MAY-2015 |
| Minimum Order Quantity: | 1 Set |
| Price: | RMB/USD/EURO |
| Packaging Details: | Standard packing for sea transportation |
| Delivery Time: | 60 to 120 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 50 to 60 sets per month |
| Product Name: | Automatic Sheet Metal Panel Bender | Double Edge Minimum Inner Size: | 140 Mm |
|---|---|---|---|
| Max Bending Thickness: | 3.0 Mm | Voltage: | 380V/50HZ |
| Axis Quantity: | Standard Synchronized 15 Axis | Max Bending Length: | 2000mm |
| Motor Power: | 77KW | Four Edge Minimum Inner Size: | 140*190 Mm |
| Highlight: | 15 Axis Sheet Metal Panel Bender,140mm Sheet Metal Panel Bender,panel bending machine 0.2Sec/Time |
||
15 Axis Standard Synchronized Sheet Metal Panel Bender Max Bending Speed 0.2 Sec/time
|
Item
|
MAY-2015
|
|
Max. bending speed
|
0 . 2 second/time
|
|
Max. bending width
|
2000mm
|
|
Max. bending height
|
170mm( 1400PC1)
|
|
300mm( 1400PC3)
|
|
|
Rated voltage
|
380v
|
|
Total motor power
|
77Kw
|
|
Average power
|
about 2. 6Kw
|
|
Noise
|
about 50dB
|
|
Machine size
|
510*265* 330cm
|
|
Total machine weight
|
about 1 8 t
|
|
Max. bending thickness
(thicker panel customizable)
|
UST 515N/ mm2 304 stainless steel 1 . 5 mm
|
|
UST 4 1 0 N/ mm2 cold panel 2 . 0 mm
|
|
|
UST 265N/ mm2 aluminum panel 3.0mm
|
|
|
Minimum panel thickness
|
0 . 35mm
|
|
Four sides forming minimum inner size
|
140* 190mm
|
|
Two sides forming minimum inner size
|
140mm
|
|
Max. bending size
|
2000* 1500mm
|
|
Axis QTY
|
standard synchronized 15 axis
|
|
Power hinge knife
|
standard
|
This sheet metal panel bender is suitable for many metal working industries, such as roofing, air conditioning, kitchen equipment, transportation, furniture, electrical appliances, and many more. It is widely used in sheet metal bending, and other CNC sheet metal bending operations. With its high-precision control system, it can be used to produce high-precision parts with the best bending quality. It has strong stability, accuracy and safety. This CNC sheet metal bending machine is widely used for the production of metal parts in various industries.
MAZS MAY-2015 sheet metal panel bender is the perfect choice for anyone who needs a reliable and efficient sheet metal bending machine. It is the perfect tool for producing high-quality parts with low-cost and high-efficiency. With its advanced CNC control system, it can provide high-precision results with a minimum of effort. This sheet metal bending machine is reliable, efficient and cost-effective, and it is the perfect choice for any metalworking industry.
Sheet Metal Panel Bender Technical Support and Service
If you are having any difficulty using your Sheet Metal Panel Bender, our technical support team is here to help. We offer a range of services to ensure you get the most out of your machine, including:
If you need any assistance with your Sheet Metal Panel Bender, please do not hesitate to contact us. Our team is always available to answer any questions you may have.
