WUXI MAZS MACHINERY SCIENCE & TECHNOLOGY CO., LTD.
| Place of Origin: | China |
|---|---|
| Brand Name: | MAZS |
| Certification: | CE, ISO |
| Model Number: | MAY-2515 |
| Minimum Order Quantity: | 1 Set |
| Price: | RMB/USD/EURO |
| Packaging Details: | Standard packing for sea transportation |
| Delivery Time: | 60 to 120 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 50 to 60 sets per month |
| Max Bending Width: | 2500mm | Max Bending Length: | 2500mm |
|---|---|---|---|
| Motor Power: | 79KW | Axis Quantity: | Standard Synchronized 15 Axis |
| Weight: | 23000KG | Four Edge Minimum Inner Size: | 140*190 Mm |
| Product Name: | Automatic Sheet Metal Panel Bender | Max Feeding Speed: | 0.2 Sec/time |
| Highlight: | 0.2 Sec/time sheet metal panel bender,MAZS sheet metal panel bender 2500mm,MAZS 50HZ automatic sheet bending machine |
||
Sheet Metal Panel Bender Max Feeding Speed 0.2 Sec/time Max Bending Width 2500mm 380V/50HZ
MAY- 2515 intelligent panel bender adopts pressing arm feeding method, and the whole machine is designed and produced according to the standard of high-precision machine tools. It is suitable for mesh, corrugated, hollow and various flat or special-shaped work pieces. It has more functions such as automatic reposition, oblique reposition, double C-axis rotation, wider range of application, and outstanding performance in terms of stability, reliability, etc.
| Item | MAY-2515 |
| Max. bending speed | 0 . 2 second/time |
| Max. bending width | 2500mm |
|
Max. bending height
|
170mm( standard) |
| 300mm( customized) | |
| Rated voltage | 380v |
| Total motor power | 79Kw |
| Average power | about 2.9Kw |
| Noise | about 50dB |
| Machine size | 565* 300* 340cm |
| Total machine weight | about 2 3 t |
|
Max. bending thickness (thicker panel customizable)
|
UST 515N/ mm2 304 stainless steel 1 . 5 mm |
| UST 410N/ mm2 cold panel 2 . 0 mm | |
| UST 2 6 5 N/ mm2 aluminum panel 3 . 0 mm | |
| Minimum panel thickness | 0 . 35mm |
| Four sides forming minimum inner size | 140* 190mm |
| Two sides forming minimum inner size | 140mm |
| Max. bending size | 2500* 1500mm |
| Axis QTY | standard synchronized 15 axis |
| Power hinge knife | standard |
The MAZS MAY-2015 Sheet Metal Panel Bender is of excellent quality and certified by IE and ISO.
MAZS MAY-2015 Sheet Metal Panel Bender is a perfect solution for sheet metal bending center. It provides precision and accuracy as well as an easy-to-use interface. Its advanced features enable it to be used in a wide range of applications, from light fabrication to heavy industry. For more information on the MAZS MAY-2015 Sheet Metal Panel Bender, contact us and we will be happy to provide you with all the details you need.
Sheet Metal Panel Bender Technical Support and Service
Our technicians are trained and certified to provide professional technical support and service for Sheet Metal Panel Benders. We provide comprehensive technical support and service to ensure the highest levels of efficiency and performance for these machines.
We offer:
Wuxi MAZS Machinery Science & Technology Co., Ltd., a high-tech enterprise, is mainly engaged in the R&D, production and sales of intelligent flexible bending centers, self-propelled integrated robotic arms, multi-axis synchronized intelligent numerical control systems , and cloud operation and maintenance management platforms.
The company has famous brand gantry boring and milling center, more than 10 sets of horizontal machining center, vertical machining center, large horizontal boring and milling machine, more than 20 sets of FANUC high-precision slow-feeding machine tools, and Hangzhou grinding machine and many other processing equipment.
Q1: What is the brand name of this product?
A1: The brand name of this product is MAZS.
Q2: What is the model number of this product?
A2: The model number of this product is MAY-2015.
Q3: Where is this product made?
A3: This product is made in China.
Q4: What certifications does this product have?
A4: This product has IE and ISO certifications.
Q5: What is the minimum order quantity?
A5: The minimum order quantity is 1 set.
