380V 50HZ Automated intelligent Sheet Metal Bending Machine Metal Edge Bender 140mm 15000KG

380V 50HZ Automated intelligent Sheet Metal Bending Machine Metal Edge Bender 140mm 15000KG
380V 50HZ Automated intelligent Sheet Metal Bending Machine Metal Edge Bender 140mm 15000KG 380V 50HZ Automated intelligent Sheet Metal Bending Machine Metal Edge Bender 140mm 15000KG 380V 50HZ Automated intelligent Sheet Metal Bending Machine Metal Edge Bender 140mm 15000KG
Basic Information
Place of Origin: China
Brand Name: MAZS
Certification: CE, ISO
Model Number: MAY-1415
Minimum Order Quantity: 1 Set
Price: RMB/USD/EURO
Packaging Details: Standard packing for sea transportation
Delivery Time: 60 to 120 days
Payment Terms: T/T, L/C
Supply Ability: 50 to 60 sets per month
Get Best Price Contact Now
Four Edge Minimum Inner Size: 140*190 Mm Max Bending Length: 1400mm
Weight: 15000KG Voltage: 380V/50HZ
Max Bending Width: 1400mm Motor Power: 38KW
Axis Quantity: Standard Synchronized 15 Axis Max Bending Thickness: 3.0 Mm
Highlight:

380V automated sheet metal bending machine

,

50HZ automated sheet metal bending machine

,

metal edge bender 140mm

380V/50HZ Automatic Panel Bender Double Edge Min. Inner Size 140mm 15000KG







Product Description:

This series of sheet metal panel benders supplied by Wuxi MAZS are intelligent and flexible bending centers that is designed for precision machine tooling. Feeding is done via pressing arm. It is strengthened with three axises and three motors. All the sheet metal panel bender is of excellent quality and certified by IE and ISO. This series of sheet metal panel bender is a perfect solution for sheet metal bending center. It provides precision and accuracy as well as an easy-to-use interface. Its advanced features enable it to be used in a wide range of applications, from light fabrication to heavy industry.
For more information on the sheet metal panel bender, contact us and we will be happy to provide you with all the details you need.





Technical Parameters:



Item MAY-1415
Max. bending speed 0 . 2 second/time
Max. bending width 1400mm

Max. bending height



 170mm
300mm( customized)
Rated voltage 380v
Total motor power 38Kw
Average power about 1.9Kw
Noise about 50dB
Machine size 440* 190* 290cm
Total machine weight about 1 5 t

Max. bending thickness

(thicker panel customizable)



 UST 515N/ mm2 304 stainless steel 1 . 5 mm
UST 410N/ mm2 cold panel 2 . 0 mm
UST 2 6 5 N/ mm2 aluminum panel 3 . 0 mm
Minimum panel thickness 0 . 35mm
Four sides forming minimum inner size 140* 190mm
Two sides forming minimum inner size 140mm
Max. bending size 1400* 1400mm
Axis QTY standard synchronized 15 axis
Power hinge knife standard






Features:

- Computer numerical control (CNC) intelligently controls and coordinates the bending process, allowing for precise and automatic bending operations.
- With convenient quick tool change point, can efficiently produce a variety of bent profiles.
- It can automatically detect the thickness of the sheet metal to be machined to ensure accurate bending parameters and avoid errors caused by incorrect material Settings.
- Bending parameters can be adjusted based on real-time feedback from the sensor, ensuring consistency and accuracy of bending even when material properties change.
- The operator or supervisor can remotely monitor the operation of the machine, diagnose problems and make adjustments.
It can be automatically adjusted according to the program parameters to increase the setting time and minimize errors.
Data related to each bending operation can be recorded and stored for analytical, quality control and reporting purposes.





Product examples:

MAZS intelligent panel bender adopts universal bending mold, cost-saving and better efficiency . It could be used for various types of panel shape.



380V 50HZ Automated intelligent Sheet Metal Bending Machine Metal Edge Bender 140mm 15000KG 0





Application:

The automatic intelligent CNC bending machine mainly solves the forming and bending problems of various complex sheet materials in sheet metal forming. Through multi-axis linkage, the equipment automatically completes the sheet metal folding work, which solves the dependence on mold and manual from a technical point of view, effectively improves the production efficiency and reduces the production cost. This set of bending centers can easily achieve curved, circular arc, crushed edge, loop shape, closed shape and other complex sheet metal bending requirements.
This automatic intelligent bending center can be widely used in steel cabinet shell (eg. file cabinet, tool cabinet, electrical cabinet, communication cabinet, gas cabinet, water meter cabinet...), kitchenware (refrigerator, air conditioner, stove...), metal forming problems in furniture, ventilation, refrigeration, purification, door industry, decoration, elevator and other related fields.
Wuxi MAZS can produce various models with bend sizes of 1400mm, 2000mm and 2500mm.

380V 50HZ Automated intelligent Sheet Metal Bending Machine Metal Edge Bender 140mm 15000KG 1





Production Capacity:

Wuxi MAZS Machinery Science & Technology Co., Ltd., a high-tech enterprise, is mainly engaged in the R&D, production and sales of intelligent flexible bending centers, self-propelled integrated robotic arms, multi-axis synchronized intelligent numerical control systems , and cloud operation and maintenance management platforms.
The company has famous brand gantry boring and milling center, more than 10 sets of horizontal machining center, vertical machining center, large horizontal boring and milling machine, more than 20 sets of FANUC high-precision slow-feeding machine tools, and Hangzhou grinding machine and many other processing equipment.

380V 50HZ Automated intelligent Sheet Metal Bending Machine Metal Edge Bender 140mm 15000KG 2



Delivery and Packing:

Automatic bending machine packaging and transportation:
- Packaging: The CNC bending machines are safely packed and securely secured with polystyrene foam and other protective materials to provide protection from shock and vibration and prevent machine damage during transportation.
- Transportation: The CNC bending machines are usually transported by sea, and the actual transportation method depends on customer requirements and destinations.

380V 50HZ Automated intelligent Sheet Metal Bending Machine Metal Edge Bender 140mm 15000KG 3​



Support and Services:

Our Automatic Sheet Metal Panel Bender offers comprehensive technical support and service. We provide efficient, reliable and quality services to our customers. Our technical support team is available 24/7 and provides:

- Troubleshooting assistance

- Installation and setup guidance

- Software and hardware updates

- Product maintenance and repair

- User manual and documentation

- FAQs and support forums

- Live chat and telephone support







FAQ:

Q1: What is the brand name of the Sheet Metal Panel Bender?
A1: The Sheet Metal Panel Bender is from MAZS. Q2: What is the model number of the Sheet Metal Panel Bender?
A2: The model number of the Sheet Metal Panel Bender is MAY-2015. Q3: What is the place of origin of the Sheet Metal Panel Bender?
A3: The Sheet Metal Panel Bender is from China. Q4: What certifications does the Sheet Metal Panel Bender have?
A4: The Sheet Metal Panel Bender has certifications of IE and ISO. Q5: What is the minimum order quantity for the Sheet Metal Panel Bender?
A5: The minimum order quantity for the Sheet Metal Panel Bender is 1 set.
