WUXI MAZS MACHINERY SCIENCE & TECHNOLOGY CO., LTD.
| Place of Origin: | China |
|---|---|
| Brand Name: | MAZS |
| Certification: | CE, ISO |
| Model Number: | MAY-**** |
| Minimum Order Quantity: | 1 Set |
| Price: | RMB/USD/EURO |
| Packaging Details: | wooden case, polystyrene foam and other protective materials suitable for sea transportation |
| Delivery Time: | 60 days to 120 days |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 50 to 60 sets per month |
| Four Edge Minimum Inner Size: | 160*210mm | Max Bending Speed: | 0.2 Set/time |
|---|---|---|---|
| Weight: | 18000KG | Model: | MAY-**15A |
| Surface Treatment: | Painting | Max. Bending Thickness: | 304 Stainless Steel 2.0mm; Cold Panel 3.0mm |
| Rated Voltage: | 380V | Bending Material: | Stainless Steel, Cold Panel |
| Highlight: | High Precision Metal Sheet Bending Machine,160 x 210mm Metal Sheet Bending Machine,cnc metal bending machine for Furniture |
||
When it comes to sheet metal forming, our Metal Sheet Bending Machine is the ideal choice due to its superior performance and high accuracy. It is a reliable and durable machine for bending sheet metal with precision. Its advanced CNC bending technology ensures the highest quality and accuracy of the final product.
Our Metal Sheet Bending Machine is suitable for a wide range of applications, from small scale to large scale sheet metal forming. It is designed to be easy to use and maintain, and it is highly efficient and cost-effective. It is the perfect choice for any sheet metal forming needs.
|
Description
|
Technical Parameters
|
| Work table structure | brush |
| System minimum accuracy | 0.001mm |
| Max. bending speed | 0.2 second/time |
| Max. feeding speed | 90m/min |
| Max. bending width | 1400mm |
| Max. bending size | L 1400mm X W 1400mm |
|
Max. bending height (The maximum bending height after customization can reach 300mm) |
170mm 300mm(customizable) |
| Min. bending height | 3mm |
| Min. arc radius | 0.5mm |
| Rated power | 380V |
| Motor power | 40KW |
| Average power | About 1.9KW |
| Noise | About 50 dB |
| Machine size | L440cm X W190cm X H290cm |
| Total weight | About 12 tons |
| User operating environment | Win7 or above system |
| Max. bending width |
UTS 515N/mm2 304 stainless steel 1.5mm UTS 410N/mm2 cold panel 2.0 mm UTS 265N/mm2 aluminum panel 3.0mm |
| Min. panel width | 0.35mm |
| Four side forming min. inner size | About 140mmx190mm(excluding inverted folded side) |
| Double side forming min. inner size | About 140mm |
| Bending angle | 0-180 degree |
| Axis | 15 |
