WUXI MAZS MACHINERY SCIENCE & TECHNOLOGY CO., LTD.
| Place of Origin: | China |
|---|---|
| Brand Name: | MAZS |
| Certification: | CE, ISO |
| Minimum Order Quantity: | 1 Set |
| Price: | RMB/USD/EURO |
| Packaging Details: | wooden case, polystyrene foam and other protective materials |
| Delivery Time: | 60 days to 120 days |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 50 to 60 sets per month |
| Product Name: | Automatic Panel Bender | Dimension: | 6000*3000*2500mm |
|---|---|---|---|
| Weight: | 2500KG | Max Bending Angle: | 135° |
| Max Bending Radius: | 200mm | Voltage: | 380V |
| Motor Power: | 4.5KW | Max Bending Width: | 1500mm |
| Highlight: | MAZS Automatic bending machine plates,MAZS 6000 X 3000 X 2500mm bending machine plates,2500KG automatic bending center MAZS |
||
Why CNC Panel Bender is a Necessary Tool for High-Quality Bending
CNC panel bender is specifically designed to efficiently and accurately bend and form metal plates. It utilizes computer numerical control (CNC) technology to automate the bending process, to ensure it is accurate and consistent. This machine is furnished with a selection of tools and rollers that can be used to manipulate the metal plate to obtain precise angles and radii. With the capability of working with a wide variety of panels sizes and thickness, great versatility is offered for sheet metal fabrication. It is most used in industries such as automotive, aerospace and electronics, where high-quality panel bending is essential.
The CNC system manages and governs the activities of the bending center, from panel positioning to the selection of pressing tools and bending parameters, leading to an efficient and repeatable bending operation. The automation of the panel bending by CNC panel bending machines increases productivity, reduces labor costs, and reduces the chance of making errors. This machine is an important device for sheet metal manufacturers that want to make sure that accurate and consistent panel bending is achieved, as well as optimize production efficiency.
- The universal mold can automatically adjust according to the size set by the program without any adjustment time, ensuring the safety of the operator and the quality of the product.
- The universal bending knife does not require mold replacement time, and it adjusts in real-time according to the length of the workpiece to ensure the quality of the workpiece. As there is no need for manual operation, the personal safety of the operator is greatly guaranteed.
- The positioning process is only completed once at the beginning of the entire bending cycle, during which the operation is carried out. The start of the stop and the rotation part are controlled. During the bending cycle, the clamping and rotation of the sheet remain unchanged, and due to continuous rotation, the 0.01 ° angle resolution ensures high production flexibility.
- The flexible servo bending center minimizes manual intervention and fully utilizes available resources. After initial offline programming, it runs completely autonomously.
| Item | Specifications |
|---|---|
| Product Name | Automatic Panel Bender |
| Max. Bending Angle | 135° |
| Max. Bending Width | 1500mm |
| Voltage | 380V |
| Product Type | Bending Machine |
| Max Bending Speed | 8m/min |
| Max Bending Thickness | 2mm |
| Control Type | CNC |
| Dimension | 6000*3000*2500mm |
| Max. Bending Length | 3000mm |
