WUXI MAZS MACHINERY SCIENCE & TECHNOLOGY CO., LTD.
| Place of Origin: | China |
|---|---|
| Brand Name: | MAZS |
| Certification: | CE, ISO |
| Model Number: | MAY-**15 |
| Minimum Order Quantity: | 1 Set |
| Price: | RMB/USD/EURO |
| Packaging Details: | wooden case, polystyrene foam and other protective materials suitable for sea transportation |
| Delivery Time: | 60 days to 120 days |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 50 to 60 sets per month |
| Name: | Custom Sheet Metal Bending Center | Bending Material: | Stainless Steel, Cold Panel |
|---|---|---|---|
| Surface Treatment: | Painting | Two Sides Forming Minimum Inner Size: | 160mm |
| Average Power: | Approx. 2.5KW | Noise: | Approx. 50dB |
| Machine Size: | 5100*2650*3300mm | Warranty: | 1 Year |
| Highlight: | 160mm aluminum sheet bending machine,2.5KW aluminum sheet bending machine,Pressing arm industrial metal bending machine |
||
|
Technical parameters
|
|
|
Feeding structure
|
Pressing arm
|
|
Work table structure
|
brush
|
|
System minimum accuracy
|
0.001mm
|
|
Max bending speed
|
0.2 second/time
|
|
Max feeding speed
|
90m/min
|
|
Max.bending width
|
1400mm
|
|
Max.bending size
|
L 1400mm X W 1400mm
|
|
Max. bending height
(The maximum bending height after customization can reach 300mm)
|
170mm
300mm(customizable)
|
|
Min. bending height
|
3mm
|
|
Min.arc radius
|
0.5mm
|
|
Rated power
|
380V
|
|
Motor power
|
40KW
|
|
Average power
|
About 1.9KW
|
|
Noise
|
About 50 dB
|
|
User operating environment
|
Win7 or above system
|
|
Max. bending width
|
UTS 515N/mm2 304 stainless steel 1.5mm
UTS 410N/mm2 cold panel 2.0 mm
UTS 265N/mm2 aluminum panel 3.0mm
|
|
Min. panel width
|
0.35mm
|
|
Four side forming min. inner size
|
About 140mmx190mm( excluding inverted folded side)
|
|
Double side forming min. inner size
|
About 140mm
|
|
Bending angle
|
0-180 degree
|
|
Axis
|
15
|
A: The brand name of the Metal Sheet Bending Machine is MAZS.
A: The Metal Sheet Bending Machine is manufactured in China.
A: The Metal Sheet Bending Machine is packaged with wooden case, polystyrene foam and other protective materials
suitable for sea transportation.
A: The delivery time for the Metal Sheet Bending Machine is 60 days to 120 days.
A: The supply ability of the Metal Sheet Bending Machine is 50 to 60 sets per month.
