WUXI MAZS MACHINERY SCIENCE & TECHNOLOGY CO., LTD.
| Place of Origin: | China |
|---|---|
| Brand Name: | MAZS |
| Certification: | CE, ISO |
| Model Number: | MAX-1009 |
| Minimum Order Quantity: | 1 Set |
| Price: | RMB/USD/EURO |
| Packaging Details: | Standard packing for sea transportation |
| Delivery Time: | 60 to 120 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 50 to 60 sets per month |
| Weight: | 7000 KGS | Product Name: | Automatic Sheet Bending Machine |
|---|---|---|---|
| Max Bending Thickness: | 1.6MM | Voltage: | 380KV |
| Max Bending Width: | 1000mm | Model: | MAX-1009 |
| Max Feeding Speed: | 0.2 Sec/time | Max Bending Height: | 170mm |
| Highlight: | 7000KGS automatic metal sheet bending machine,1.1KW automatic metal sheet bending machine,steel sheet folding machine 1000mm |
||
The Intelligent pressing arm type panel bender has developed a servo flexible bending center with international advanced level after 5 years of research and development. The products are independently developed from software drivers, hardware circuits to mechanical structures. The panel bender buyers are from domestic and overseas market, covering a number of ten industries have won unanimous praise from consumers! The intelligent pressing arm type panel bender/ flexible bending center is a high-tech product developed and produced for the sheet metal industry to improve production efficiency, reduce labor intensity and enhance corporate image.
| Models | MAX-1009 |
| Max. bending speed | 0.2 second/time |
| Max. bending width | 1000mm |
| Bending hight | 170mm |
| Rated voltage | 380v |
| Motor total power | 25Kw |
| Average power | about 1. 1Kw |
| Noise | about 50dB |
| Machine size | 285* 150* 280cm |
| Total machine weight | about 7t |
|
Max. bending thickness (thicker panel customizable) |
UST 5 1 5 N/ mm2 3 0 4 stainless steel 1 . 0 mm |
| UST 4 1 0 N/ mm2 cold panel 1 . 2 mm | |
| UST 265N/ mm2 aluminum panel 1 . 6mm | |
| Minimum panel thickness | 0 . 35mm |
| Four sides forming, minimum inner size | 140* 210mm |
| Double sides forming minimum inner size | 140mm |
| Max. bending size | 1000* 1000mm |
| Axis quantity | Standard synchronized 9 axises |
| Power horn blank holder | optional |
The automatic intelligent panel bender bending center mainly solves the forming and bending problems of various complex sheet materials in sheet metal forming. Through multi-axis linkage, the equipment automatically completes the sheet metal folding work, which solves the dependence on mold and manual from a technical point of view, effectively improves the production efficiency and reduces the production cost. This set of bending centers can easily achieve curved, circular arc, crushed edge, loop shape, closed shape and other complex sheet metal bending requirements.
This automatic intelligent bending center can be widely used in steel cabinet shell (eg. file cabinet, tool cabinet, electrical cabinet, communication cabinet, gas cabinet, water meter cabinet...), kitchenware (refrigerator, air conditioner, stove...), metal forming problems in furniture, ventilation, refrigeration, purification, door industry, decoration, elevator and other related fields.
Wuxi MAZS can produce various models with bend sizes of 1400mm, 2000mm and 2500mm.
Welcome to consult Wuxi MAZS Machinery Group on intelligent CNC system bending Center.
1. After the equipment is checked and accepted, the quality guarantee period of the whole machine is one year.
2. During the warranty period of the equipment, Wuxi MAZS is responsible for free replacement or maintenance of parts due to the quality of the equipment itself, except for conventional consumables (such as suction cups) and those that are responsible for the user's illegal operation.
3. Wuxi MAZS provides life-long maintenance services for the products provided, and provides daily consultation and guidance related to equipment at any time. Outside the warranty period, our company still provides extensive and preferential technical support and spare parts supply for the buyer. For each device, Wuxi MAZS will establish a uniquely coded "user profile" to track and record the relevant information of the user using the equipment. uxi MAZS will promptly notify the buyer of the software upgrade situation. Except for new requirements, we provide daily software upgrade services free of charge.
4. Wuxi MAZS has sufficient spare parts and accessories, which can provide technical services and spare parts services to the buyer in time to meet the needs of equipment maintenance.
5. If you want to know more about the product, please log in to our website or contact the after-sales staff labeled on the equipment, we have a professional team to serve you wholeheartedly.
